Creating a low-cost USB Rubber Ducky With Raspberry Pi Pico

USB Rubber Ducky

USB Rubber ducky is a Human Interface Device that looks similar to a USB Pen drive.USB Rubber ducky cannot be detected by any Anti-Virus or Firewall as it acts as a Human Interface Device. It is used to inject malicious scripts, used to create remote access to a victim's PC, steal the victim’s credential data, and can inject payload to the victim’s computers.

Rasberry pi pico

Get one Pico board from here .

Process

1. Download CircuitPython for the Raspberry Pi Pico by clicking it.

2. Plugin the Rasberry pi pico into the USB port. It will show up as a device named RPI-RP2.

3. Copy the downloaded .uf2 file(circuit Python) to the root of the Pico (RPI-RP2).

4. It will reboot automatically, it will reconnect as CIRCUITPY.

5. Download adafruit-circuitpython-bundle-6.x-mpy-20210930.zip and extract it using Winrar.

6. Open lib in the recently extracted folder and copy adafruit_hid to the lib folder in your Raspberry Pi Pico.

7. Now open code.py delete the previous code and copy-paste the below code and save it.

import usb_hid
from adafruit_hid.keyboard import Keyboard
from adafruit_hid.keyboard_layout_us import KeyboardLayoutUS
from adafruit_hid.keycode import Keycode
import time
import digitalio
from board import *

duckyCommands = {
    'WINDOWS': Keycode.WINDOWS, 'GUI': Keycode.GUI,
    'APP': Keycode.APPLICATION, 'MENU': Keycode.APPLICATION, 'SHIFT': Keycode.SHIFT,
    'ALT': Keycode.ALT, 'CONTROL': Keycode.CONTROL, 'CTRL': Keycode.CONTROL,
    'DOWNARROW': Keycode.DOWN_ARROW, 'DOWN': Keycode.DOWN_ARROW, 'LEFTARROW': Keycode.LEFT_ARROW,
    'LEFT': Keycode.LEFT_ARROW, 'RIGHTARROW': Keycode.RIGHT_ARROW, 'RIGHT': Keycode.RIGHT_ARROW,
    'UPARROW': Keycode.UP_ARROW, 'UP': Keycode.UP_ARROW, 'BREAK': Keycode.PAUSE,
    'PAUSE': Keycode.PAUSE, 'CAPSLOCK': Keycode.CAPS_LOCK, 'DELETE': Keycode.DELETE,
    'END': Keycode.END, 'ESC': Keycode.ESCAPE, 'ESCAPE': Keycode.ESCAPE, 'HOME': Keycode.HOME,
    'INSERT': Keycode.INSERT, 'NUMLOCK': Keycode.KEYPAD_NUMLOCK, 'PAGEUP': Keycode.PAGE_UP,
    'PAGEDOWN': Keycode.PAGE_DOWN, 'PRINTSCREEN': Keycode.PRINT_SCREEN, 'ENTER': Keycode.ENTER,
    'SCROLLLOCK': Keycode.SCROLL_LOCK, 'SPACE': Keycode.SPACE, 'TAB': Keycode.TAB,
    'A': Keycode.A, 'B': Keycode.B, 'C': Keycode.C, 'D': Keycode.D, 'E': Keycode.E,
    'F': Keycode.F, 'G': Keycode.G, 'H': Keycode.H, 'I': Keycode.I, 'J': Keycode.J,
    'K': Keycode.K, 'L': Keycode.L, 'M': Keycode.M, 'N': Keycode.N, 'O': Keycode.O,
    'P': Keycode.P, 'Q': Keycode.Q, 'R': Keycode.R, 'S': Keycode.S, 'T': Keycode.T,
    'U': Keycode.U, 'V': Keycode.V, 'W': Keycode.W, 'X': Keycode.X, 'Y': Keycode.Y,
    'Z': Keycode.Z, 'F1': Keycode.F1, 'F2': Keycode.F2, 'F3': Keycode.F3,
    'F4': Keycode.F4, 'F5': Keycode.F5, 'F6': Keycode.F6, 'F7': Keycode.F7,
    'F8': Keycode.F8, 'F9': Keycode.F9, 'F10': Keycode.F10, 'F11': Keycode.F11,
    'F12': Keycode.F12,
}

def convertLine(line):
    newline = []
    print(line)
    # loop on each key - the filter removes empty values
    for key in filter(None, line.split(" ")):
        key = key.upper()
        # find the keycode for the command in the list
        command_keycode = duckyCommands.get(key, None)
        if command_keycode is not None:
            # if it exists in the list, use it
            newline.append(command_keycode)
        elif hasattr(Keycode, key):
            # if it's in the Keycode module, use it (allows any valid keycode)
            newline.append(getattr(Keycode, key))
        else:
            # if it's not a known key name, show the error for diagnosis
            print(f"Unknown key: <{key}>")
    print(newline)
    return newline

def runScriptLine(line):
    for k in line:
        kbd.press(k)
    kbd.release_all()

def sendString(line):
    layout.write(line)

def parseLine(line):
    if(line[0:3] == "REM"):
        # ignore ducky script comments
        pass
    elif(line[0:5] == "DELAY"):
        time.sleep(float(line[6:])/1000)
    elif(line[0:6] == "STRING"):
        sendString(line[7:])
    elif(line[0:13] == "DEFAULT_DELAY"):
        defaultDelay = int(line[14:]) * 10
    elif(line[0:12] == "DEFAULTDELAY"):
        defaultDelay = int(line[13:]) * 10
    else:
        newScriptLine = convertLine(line)
        runScriptLine(newScriptLine)

kbd = Keyboard(usb_hid.devices)
layout = KeyboardLayoutUS(kbd)

# sleep at the start to allow the device to be recognized by the host computer
time.sleep(.5)

# check GP0 for setup mode
# see setup mode for instructions
progStatus = False
progStatusPin = digitalio.DigitalInOut(GP0)
progStatusPin.switch_to_input(pull=digitalio.Pull.UP)
progStatus = not progStatusPin.value
defaultDelay = 0
if(progStatus == False):
    # not in setup mode, inject the payload
    duckyScriptPath = "payload.dd"
    f = open(duckyScriptPath,"r",encoding='utf-8')
    print("Running payload.dd")
    previousLine = ""
    duckyScript = f.readlines()
    for line in duckyScript:
        line = line.rstrip()
        if(line[0:6] == "REPEAT"):
            for i in range(int(line[7:])):
                #repeat the last command
                parseLine(previousLine)
                time.sleep(float(defaultDelay)/1000)
        else:
            parseLine(line)
            previousLine = line
        time.sleep(float(defaultDelay)/1000)

    print("Done")
else:
    print("Update your payload")

8. Find a script here and save it as payload.dd in the Pico.

9. Be careful, if your device isn't in setup mode, the device will reboot and after half a second, the script will run.

10. To edit the payload, enter setup mode by connecting the pin 1 (GP0) to pin 3 (GND), this will stop the pico-ducky from injecting the payload in your own machine. The easiest way to so is by using a jumper wire between those pins as seen bellow.
